Semiautomatic Handle Paper Edge Waste Stripper Cardboard

Products

Semiautomatic Handle Paper Edge Waste Stripper Cardboard

Type:air waste stripper

Weight:5.5KG

Chain:#3 chain

Revolution:4500 RPM

Working pressure:6~8KG

Motor:Taiwan Brand

Paper type:it suitable for all kinds of paper, especially for corrugating medium paper/paperboard

  • Details

Semiautomatic Handle Waste Stripper Cardboard /corrugated Paper Edge Cutting Machine Pneumatic Stripping Machine Carton Stripper



PRODUCT SPECIFICATION

Item Number

HS-881S

Type

Pneumatic stripper

Color

Orange

Revolution

4500 turns /min

Chain

#3 with 18 cogs (medium size)

Air consumption

0.4㎡/min

Working pressure

6~8 KG

Net weight

3.5 KG

Minimum cutting size

5MM

Suitable paper

all kinds of paper. Efficiency will be higher for corrugating medium paper/paperboard

Gross Weight

6.0KG

Package Dimensions

490*170*240mm



HS-881S waste stripping machine is an easy to use, hand held stripping device for removing waste from die-cut sheets. Suitable for all kinds of paper, such as both solid carton board. The minimum waste depth is 5mm.


The latest generation of the HS-881S is manufactured with a heavy duty motor and powerful pneumatic drive. The chain should last a minimum of six months providing the stripper is used correctly.


Stripping Time Reduced by up to 85%

Production time can also be saved on setting back and side trim removal on die cutter. The operator can strip a pallet while the next one is running through the die cutter.


Additional Features & Benefits:

Two-handed operation for safety

Hardened parts for longer life

Ultra hard chain and enclosed pneumatic for improved safety

Reduced risk of RSI

5.0mm minimum gutter depth - narrowest on the market

Undamaged cartons resulting in improved productivity


PRODUCT FEATURE

-- Famous pneumatic motor with high performance and security;

-- Lightweight portable design, it is very super convenient to use;

-- Easy and quick clear waste, high efficiency than the traditional human stripping;

--Compared with the hammer knock the waste way, don't damage bonding area when stripping;

--Chain adopt high strength alloy steel higher hardness, wear resistance, long service life.


COMMON PROBLEMS

--Tool does not work

1.Chain can not rotate, too tight or gear stuck, remove the cover, adjust the slider, check whether the chain and the gear is misaligned

2.When the machine is working. Paper jam in gear, cut off the air supply, and agitate the chain with a tool to rotate it until the shreds come out.


--Tool rotation powerless

1.Air pressure is not enough, check the air pressure to increase the pressure

2.Check whether the slide switch is on

3.The chain is too tight/too loose, try adjusting the chain to the right position

4.Chain excessive wear, the chain needs to be replaced


WHY CHOOSE US

Here are some main points.

Chain

Riveting Chain

More firmer and not hard to break.

Metal Cover

Stainless Steel Cover

It is easy to extremely hot and easy to dissipate heat, which can protect stripper by itself

Metal Handle

Stainless Steel Handle

Elegant and is high quality.

Firm structure

Three points fixation

More firmer and more stable

Inside components

Hard Coating

Longer lifetime and high quality

Motor

Famous brand

High accuracy, stability and excellent quality


PRODUCT SHOW




ORDER LIST




ORDER STEPS



How to maintain the stripper machine


1,The machine should be maintained after used 2-3 days.(once 2-3 days).
If the using time is more than 12 hrs per day, you should maintain the machine everyday.

2,Maintain operations: Two ways to maintain, manual maintain and auto maintain by oil-water separator

Manual maintain:
1, Apply the regular engine oil or pneumatic tool oil to the chain of machine;
2, Apply the specialized air-tool oil to the air inlet of machine;
3, Then turn on the machine to let it rotate about one minutes.

Auto maintain by oil-water separator
1, Install the oil-water separator onto the place which 1 or 2 meters long away to the air compressor.
2, It will maintain the machine automatically when the machine is working.
3, The details of oil-water separator as below for your reference.

More details, please contact us directly by email or whatsapp.
